Week 5

This week was an introduction to self-referential structures, linked lists, and trees.

Self-Referential Structures

A structure cannot contain a member of its own type directly, because this would require the compiler to know the full size of the structure before its layout is complete. However, a structure can contain a pointer to its own type. This allows structures to reference other structures of the same type.

This pattern is called a self-referential structure.

Nodes

A node is a fundamental building block used in several data structures (including linked lists, stacks, queues, and trees). A node stores its own data and one or more pointers that describe how to reach other nodes.

Because these pointers refer to other nodes of the same type, nodes are self-referential.

struct node
{
    int data;
    struct node *nextPtr;
};

Linked Lists

A linked list is a linear collection of self-referential nodes connected by pointer links.

Unlike an array, a linked list does not require contiguous memory. Each node is allocated separately, and each node stores:

Its data
A pointer to the next node in the list (nextPtr)

The list is accessed through a pointer to the first node, commonly called the head. If the list is empty, the head pointer is set to NULL.

struct node
{
    int data;
    struct node *nextPtr;
};

Basic Linked List

The last node in the list has a nextPtr of NULL, indicating that no further nodes follow.

Traversing a Linked List

To process each element, we use a pointer that starts at the head and moves from node to node until NULL is reached.

struct node *current = head;

while (current != NULL)
{
    printf("%d ", current->data);
    current = current->nextPtr;
}

Arrays vs Linked Lists

Both arrays and linked lists store collections of data, but they differ in how memory is managed and how elements are accessed.

When Linked Lists Are Useful

A linked list is appropriate when the number of data items is unknown or changes over time.
Linked lists are dynamic: nodes can be added or removed as needed at runtime.
Useful when elements will be frequently inserted or deleted, especially in the middle of the sequence.

When Arrays Are Useful

Arrays are fixed-size data structures. The size is determined when the array is created.
Arrays allow direct (constant-time) access to any element because elements are stored contiguously in memory.
Best when the total number of elements is known in advance and fast indexing is required.

Memory Considerations

Arrays may reserve more space than needed if sized too large.
Linked lists only use memory for the nodes currently stored, but each node requires extra memory for a pointer, and dynamic allocation involves overhead.

Performance Summary

Operation / Property	Array	Linked List
Size	Fixed at creation	Grows and shrinks dynamically
Memory Layout	Contiguous	Distributed (each node separately)
Access by Index	O(1) direct access	O(n) traversal
Insert/Delete at Middle	Potentially expensive (shift)	Efficient with pointer adjustments
Extra Memory Required	Only for elements	Pointer stored in each node

Inserting into a Linked List

There are two common cases for inserting a new node into a singly linked list:

When the list does not need to maintain sorted order (unsorted insertion)
When the list must remain sorted after insertion (sorted insertion)

1. Insertion in an Unsorted List

The simplest approach is to insert the new node at the beginning of the list. This avoids traversal and runs in O(1) time.

Steps:

Allocate memory for the new node.
Store the data in the new node.
Set the new node’s nextPtr to point to the current head.
Update the head to point to the new node.

newPtr->nextPtr = head;
head = newPtr;

Unsorted linked list visual

2. Insertion in a Sorted Linked List

When the list is sorted, we must find the correct position for the new node so the ordering is preserved.

We use two traversal pointers:

previousPtr (tracks the node before the insertion point)
currentPtr (used to walk the list)

Steps:

Allocate memory for the new node. If allocation fails, do not modify the list.
Store the new data in the node and set its nextPtr to NULL initially.
Initialize traversal pointers:
previousPtr = NULL
currentPtr = head
Traverse the list to locate the correct insertion point:
While currentPtr != NULL and the new value is greater than currentPtr->data:
- previousPtr = currentPtr
- currentPtr = currentPtr->nextPtr
Insert the new node:
If previousPtr is NULL, insert at beginning:
```
newPtr->nextPtr = head;
head = newPtr;
```

Otherwise, insert between previousPtr and currentPtr:

previousPtr->nextPtr = newPtr;
newPtr->nextPtr = currentPtr;

Sorted linked list visual

Deleting a Node from a Linked List

Deletion removes a node and reconnects the surrounding nodes so the list remains intact. Two common cases exist: deleting the first node and deleting a node elsewhere in the list.

1. Deleting the First Node

When the first node is removed, the head pointer must be updated to point to the second node.

Steps:

Assign a temporary pointer to the current head node.
Move the head pointer to the next node.
Free the memory of the removed node.

ListNodePtr temp = head;
head = head->nextPtr;
free(temp);

Delete from start (visual)

2. Deleting a Node Elsewhere

When deleting from the middle or end, traversal pointers are used to find the node preceding the one to remove.

Steps:

Traverse the list using two pointers:
previousPtr tracks the node before the one to delete.
currentPtr tracks the node being inspected.
Stop when currentPtr points to the node to remove.
Update previousPtr->nextPtr to skip over the deleted node.
Free the deleted node.

previousPtr->nextPtr = currentPtr->nextPtr;
free(currentPtr);

Delete elsewhere (visual)

Deleting requires careful pointer management to ensure that the remaining nodes stay properly linked and no memory leaks occur.

Checking if the List is Empty and Printing the List

These utility functions help inspect a linked list without modifying it.

Checking if the List is Empty

The isEmpty function determines whether a linked list contains any nodes.

int isEmpty(ListNodePtr sPtr)
{
    return sPtr == NULL;
}

Printing the List

The printList function traverses the list and displays its contents. If the list is empty, it reports that to the user; otherwise, it prints each node’s data value in sequence.

void printList(ListNodePtr currentPtr)
{
    if (isEmpty(currentPtr))
    {
        puts("List is empty.\n");
    }
    else
    {
        puts("The list is:");

        while (currentPtr != NULL)
        {
            printf("%c --> ", currentPtr->data);
            currentPtr = currentPtr->nextPtr;
        }

        puts("NULL\n");
    }
}

This function is often used for debugging or visualizing the list’s current state after insertions or deletions.

Merging Two Sorted Lists

initialize pointers
1. prevPtr points to NULL
2. currPtr points to beginning of list1
3. tempPtr points to beginning of list2
Loop through each element of list2 (using tempPtr)
1. find the correct insertion point in list 1
  1. walk the pointers until tempPtr->data is less than or equal to currentPtr->data or currentPtr becomes NULL
2. Insert the node
  1. if prevPtr is NULL then insert at head by
    1. pointing the List2 pointer to the tempPtr->next node
    2. updating the tempPtr->next node to point to the List1 pointer
    3. updating the List1 pointer to point to the tempPtr
  2. otherwise:
    1. pointing the List2 pointer to the tempPtr->next node
    2. updating the prevPtr>next node to point to the tempPtr
    3. updating the tempPtr->next to point to the currentPtr
3. Advance the pointers
  1. move prevPtr to the tempPtr node
  2. move tempPtr to the List2 pointer.

Merge (visual)

Trees

A tree is a nonlinear, two-dimensional data structure made up of nodes. Unlike linear structures such as arrays or linked lists, trees organize data hierarchically.

Each node in a tree may contain multiple links to other nodes. In a binary tree, each node contains two links—commonly called the left and right child pointers. Either or both of these links can be NULL.

Basic Tree Structure

Basic Terminology

Root node – The topmost node in the tree. It serves as the entry point.
Child node – A node referenced by another node.
Parent node – A node that links to one or more children.
Left child – The first node in the left subtree of a parent.
Right child – The first node in the right subtree of a parent.
Siblings – Nodes that share the same parent.
Leaf node – A node with no children (both links are NULL).

Other Notes

Not setting a leaf node’s links to NULL can lead to runtime errors.
A tree may be empty (no root node) or contain a hierarchy of nodes connected by pointers.
In computer science diagrams, trees are typically drawn with the root at the top, opposite of how trees appear in nature.

Binary Search Tree (BST)

A binary search tree (BST) is a special type of binary tree that stores unique values and maintains a specific ordering property:

All values in the left subtree of a node are less than the value in the node’s parent.
All values in the right subtree are greater than the value in the node’s parent.

This ordering allows efficient search, insertion, and deletion operations.

Binary Search Tree Example

In the example above, the tree has nine values. Notice that:

Every left child is smaller than its parent.
Every right child is larger than its parent.
The shape of a BST depends on the order of insertion. Inserting the same numbers in a different order can produce a completely different tree structure.

This property enables fast lookups—on average O(log n) time—but in the worst case (such as inserting sorted data without balancing) performance can degenerate to O(n).

Preorder Traversal (Root → Left → Right)

In a preorder traversal, each node is visited before its subtrees:

Visit the root.
Traverse the left subtree.
Traverse the right subtree.

This means the root is always processed first.

Pre-order Traversal Visual

Inorder Traversal (Left → Root → Right)

In an inorder traversal, the order ensures that nodes are visited in sorted order for a binary search tree:

Traverse the left subtree.
Visit the root.
Traverse the right subtree.

This traversal is often used to output data in ascending order.

In-order Traversal Visual

Postorder Traversal (Left → Right → Root)

In a postorder traversal, subtrees are processed before the parent node:

Traverse the left subtree.
Traverse the right subtree.
Visit the root.

This traversal is useful for deleting or freeing nodes, since children are handled before their parent.

Post-order Traversal Visual

Pointer-to-Pointer Parameters and the `insertNode` Example

The pointer-to-pointer pattern is required when a function must modify a pointer owned by the caller (e.g., the tree’s root or a child link). Passing the address of that pointer lets the function assign to it directly.

void insertNode(TreeNodePtr *treePtr, int value)
{
    if (*treePtr == NULL) {
        *treePtr = malloc(sizeof **treePtr);
        if (*treePtr) {
            (*treePtr)->data = value;
            (*treePtr)->leftPtr = NULL;
            (*treePtr)->rightPtr = NULL;
        } else {
            printf("%d not inserted. No memory available.\n", value);
        }
        return;
    }

    if (value < (*treePtr)->data) {
        insertNode(&((*treePtr)->leftPtr), value);
    } else if (value > (*treePtr)->data) {
        insertNode(&((*treePtr)->rightPtr), value);
    } else {
        printf("dup\n");
    }
}

treePtr has type TreeNode ** (pointer to a TreeNode *).
*treePtr is the actual TreeNode * (root or a child link).
(*treePtr)->member accesses a field of the node that *treePtr points to.

Why `&((*treePtr)->leftPtr)`?

When you recurse left or right, you must pass the address of the child pointer so the callee can update that pointer in place.

(*treePtr)->leftPtr has type TreeNode * (a child link).
&((*treePtr)->leftPtr) therefore has type TreeNode ** — exactly what insertNode expects.

This is the critical difference: you are not passing the address of the node; you are passing the address of the pointer that stores the child link.

// Types at each step
TreeNodePtr  left   = (*treePtr)->leftPtr;   // TreeNode *
TreeNodePtr *target = &((*treePtr)->leftPtr); // TreeNode **
insertNode(target, value);                   // matches parameter type

Operator precedence and parentheses

-> binds tighter than unary &, so &(*treePtr)->leftPtr would be parsed the same as &((*treePtr)->leftPtr).
The extra parentheses are kept for readability and to avoid misreading the expression as &*treePtr (which simplifies to treePtr, not the child field’s address).

Contrast:

&*treePtr → treePtr (type TreeNode **), the address-of followed by dereference cancels out.
&((*treePtr)->leftPtr) → address of the left child pointer field inside the node pointed to by *treePtr.

A helpful way to read it:

*treePtr → the current node pointer.
(*treePtr)->leftPtr → the left child pointer stored in that node.
&((*treePtr)->leftPtr) → the address of that child pointer (so we can assign to it inside the callee).
